Warning!. This course requires the course of Basic Electricity MTT 1400 as a Prerequisite
In this course, we are going to study all the aspects related to AC current for medium and Mega-Yachts
We are going to start with the sources of AC current, The study of the frequency (50 & 60 Hz), the amplitude, The wire color codes for American and European boats, and The wiring of the AC panels for single, double, and three phases, The bonding and lightning protection, AC and DC Motors, Transformers, The most complete study of marine generators, The process to size and configure marine inverters, Solar and wind power systems and finally how to convert Gas and diesel engines into Hybrid Boats.
Curriculum
- 10 Sections
- 55 Lessons
- Lifetime
Expand all sectionsCollapse all sections
- CHAPTER 9: AC Current5
- CHAPTER 10: Bonding and Lightning9
- 2.1EPISODE 1: Bonding System14 Minutes
- 2.2EPISODE 2: How to check and install a galvanic Isolator9 Minutes
- 2.3EPISODE 3: Isolator Transformer vs Galvanic Isolator3 Minutes
- 2.4EPISODE 4: Lightning Protection19 Minutes
- 2.5EPISODE 5: Boat Corrosion Issues Analysis
- 2.6LAB No. 1: AC Current bonding & Lightning12 Minutes
- 2.7QUIZ CHAPTER 10: Bonding and Lightning10 Questions
- 2.8CLIP: Why Reverse Polarity is Catastrophic in a Boat20 Minutes
- 2.9CLIP: Bonding and Grounding20 Minutes
- CHAPTER 11: AC Wiring5
- CHAPTER 12: AC Panel Board6
- 4.1EPISODE 1: Wiring an AC Panel / Reverse Polarity Diagnosis36 Minutes
- 4.2EPISODE 2: Dock Pedestals, wiring configuration & Troubleshooting17 Minutes
- 4.3QUIZ CHAPTER 12: AC Panel Board10 Questions
- 4.4CLIP: How a Dock Pedestal works20 Minutes
- 4.5CLIP: Advance Electricity Conference – Two Phases AC Wiring20 Minutes
- 4.6CLIP: Wiring a Single Phase Boat20 Minutes
- CHAPTER 13: Motors and Transformers7
- 5.1EPISODE 1: How AC and DC Motors works & Reversible DC Motors32 Minutes
- 5.2EPISODE 2: AC Induction Motors & Reversing AC Motors with Contactors22 Minutes
- 5.3EPISODE 3: Transformers- Step-Up, Step-Down , Isolator Transformers16 Minutes
- 5.4QUIZ CHAPTER 13: Motors and Transformers15 Questions
- 5.5CLIP: How to Check Capacitors20 Minutes
- 5.6CLIP: Reversing AC and DC Motors20 Minutes
- 5.7CLIP: Shore Power Cable Issues Diagnosis20 Minutes
- CHAPTER 14: Marine Generators18
- 6.1EPISODE 1: Generators fundamentals & Conversion from 50 Hz to 60 Hz24 Minutes
- 6.2EPISODE 2: Voltage Regulator Adjustment and Megger test procedure20 Minutes
- 6.3EPISODE 3: How to install a Marine Generator42 Minutes
- 6.4EPISODE 4: Troubleshooting Marine Generators32 Minutes
- 6.5EPISODE 5: How to design the Harness of an Engine or Generator52 Minutes
- 6.6LAB No. 3: Generators Fundamentals12 Minutes
- 6.7QUIZ CHAPTER 14: Marine Generators26 Questions
- 6.8CLIP: How to use the Megohmmeter20 Minutes
- 6.9CLIP: Install Oil Pressure Switch & Oil Pressure Sensor20 Minutes
- 6.10CLIP: Install Coolant Temp Switch’s And Sensor20 Minutes
- 6.11CLIP: LAB – Generator Fundamentals20 Minutes
- 6.12CLIP: Advance Electricity Conference / Generators20 Minutes
- 6.13CLIP: Advance Electricity Class – Relays20 Minutes
- 6.14CLIP: How to Convert a European Generator (Analog) into American 50 Hz / 60 Hz20 Minutes
- 6.15CLIP: Generators Fundamentals20 Minutes
- 6.16CLIP: Generator Fundamentals Part 220 Minutes
- 6.17CLIP: Inverters20 Minutes
- 6.18CLIP: Low Voltage in a Two Phases Generator20 Minutes
- CHAPTER 15: Inverters and UPS6
- 7.1EPISODE 1: Inverters – Sizing, Installation and ABYC Standards30 Minutes
- 7.2LAB No. 4: Marine Inverters18 Minutes
- 7.3QUIZ CHAPTER 15: Inverters and UPS10 Questions
- 7.4CLIP: Sizing an Inverter Battery Bank20 Minutes
- 7.5CLIP: Inverters and Chargers20 Minutes
- 7.6CLIP: How to Size the Battery Bank for an Inverter20 Minutes
- CHAPTER 17 & 18: Solar & Wind Power Systems4
- CHAPTER 19: Hybrid Boats3
- FINAL EXAM ADVANCE ELECTRICITY1
Requirements
- Basic Electricity Course
